Welcome to
D-T Wire EDM Services
A Premiere Wire EDM Service for the Greater Toronto Area
How EDM can help you
Why WIre edm
The wire EDM process uses a high-speed small hole driller that machines difficult to cut carbide and heat-treated workpieces quickly and efficiently.
Wire EDM can be used to cut extremely hard metals and parts with intricate shapes, and complex angles, particularly in materials which cannot be machined by traditional methods, and without high tooling cost.
D-T Wire EDM Services provides Wire EDM (Electrical Discharge Machining) Services for complex metal parts and components. Our services range from a start hole for wire cut EDM that can be done quickly and easily to complex metal parts and components.
FEATURES
- Ability to cut precisely (pitch and form accuracy, corner accuracy, circular accuracy, true direct precision)
- Ability to cut nearly square internal corners (sharp corners and no rounding of corners)
- Ability to provide Digitization Services if no CAD is available
- Ability to provide Reverse Engineering Services from your part or component
- 4 Axis capability
- Ability to work with pieces up to 12″ thick
- Small hole drilling of .3mm diameter minimum up to 6′ thick
- Faster, more accurate production runs and at lower cutting costs per square inch with shorter deliver times
- Cutting accuracy up to +/-.0001″
- High level interlocking with minimal interlocking clearances
- Slide machining of high-grade materials
- Wide angle taper machining
- Pieces with different top and bottom contours can be machined
- Maximum Angle: +/- 10 degrees in 12″ thick material
- Materials from Aluminum to Carbide
- Maximum Travel: X = 21.7″, maximum Y = 14.6″, maximum Z =12.2″
- Maximum Cutting Height: 12″ Tall
- Maximum Work Piece Dimensions: 40″ x 26 x 12
- Maximum Work Piece Weight: 1000 Lbs.
- Tolerances can be held up to .0001”
- Wire Diameters from .008” – .032”
EXPERIENCE MATCHED WITH QUALITY EQUIPMENT and percision
Our Value
- Digitization Services
- Reverse engineering Services
- Full Toolroom Services
With over 40 years of industry experience, D-T Wire EDM Services is a highly motivated, established company which combines traditional values of service, quality, and high precision, with innovation, advanced technology, versatility and flexibility.
Our team has the ability to provide you with Digitization Services if you do not have a CAD diagram. We also have the ability to Reverse Engineer your parts or components and provide you what you need. We have full toolroom services available to help us meet all your needs.
The company provides Wire EDM services to all industries including the OEM electronic and automotive industries. We can Wire EDM conductive metals from Aluminum to Carbide. Our services range from a start hole for wire cut EDM that can be done quickly and easily in minutes to structurally complex metal parts and components.
D-T Wire EDM Services operates in a safe, employee environment where customer and company expectations are exceeded through continuous improvement and innovation. The focus is on common sense, craftsmanship, maintaining customer partnerships and a dedication to our customer’s success through our commitment to the highest level of customer support.
271 AMBER ST, UNIT #4
MARKHAM, ONTARIO
L3R 3J7, CANADA
CONTACT@dtwire-edm.CA
TEL: 905-948-8725
Our Location
GOT A QUESTION OR WANT A QUOTE? WE WANT TO HEAR FROM YOU!
